Features
1.Luxurious electric lift chair, using silent type mode of operation.
2.Uses a unique auto-lock function: to prevent the eccentric wheel means insecurity.
3.Electric luxury arm, it only has about 30 degrees arbitrary adjustment method, but also up and down movements.
4.Work table can be extended outward 45 degrees, it also has Refractometer mobile disk and display optometry box drawer.

Dimensions of combined table 1020×1230×1590mm
Voltage:AC,110V/ 220V 50Hz
Power:200w
Weight 240kg

Specifications
Operation Table
Size: 1010*480*33(mm)
Height: 850mm
Rotary angle:90°
Sliding distance:460mm
Phoropter bracket
Manual control
Swing angle:53°
Chair
Chair rising distance:150mm
Power
Voltage: AC 220V/50Hz
Light power: AC 220V/18W
Package Dimensions
1115*1090*1010(mm)

Specifications
Auto rotating of operation table and phoropter,Slit lamp and refractometer could be put on .
Size: 965*500*25(mm)
Height: 860mm
Rotary angle:90
Sliding distance:350mm
Phoropter bracket
Remote control
Rising distance: 190mm
Rotary angle: 90°
Chair
Chair rising distance:150mm
Power
Voltage: AC 220V/50Hz
Light power: AC 220V/18W

Features:
·Adopts Europe style in appearance designing, simple structure, good performance, and easy operation.
·Hand-operated phoropter arm can swing up and down, left and right to its best position, which shows the human-oriented design of it.
·Worktable provides with 90 degrees’ rotation.
Sliding table to accommodate two instruments.
Auxiliary 110V/220V output under table
·Overhead light and table voltages are variably controlled via dimmer switch
·The comfortable chair can smoothly lift up and down with low noise and able to bear big force.
·Choosing different styles on the basis of inner structure of shop


Mechanical Parameters
Up/Down angle of swing arm: ±30°
Table size: 840mm×405mm
Table rotational angle: 90°
Table sliding movement: 330mm
Angle of rotation for chair: ±60°
Lifting height for chair: 150~200mm
Loading for chair: 70~150kgs
Lifting height for pillow: ＋150mm
Backrest obliquity: 90°~135°or 140°

Specifications
● Power Supply: A.C.110V or 220V,50/60Hz
● Power: 350W
● Table Height: 860mm
● Rotation of Table: 360°
● Chair Upward Movement: 190mm
● Chair Height from Ground: 540mm
● Total Weight: 200kg

Features
1.Luxurious electric lift chair, using silent type mode of operation.
2.Uses a unique auto-lock function: to prevent the eccentric wheel means insecurity.
3.Electric luxury arm, it only has about 30 degrees arbitrary adjustment method, but also up and down movements.
4.Work table can be extended outward 45 degrees, it also has Refractometer mobile disk and display optometry box drawer.

Dimensions of combined table 1020×1230×1590mm
Voltage:AC,110V/ 220V 50Hz
Power:200w
Weight 240kg
