Type Galilean-Type
Magnification change Revolving Drum
Total magnification Ratio 6x,10x, 16x, 25x,40x
professional configuration
Eyepieces 12.5x
Angle between eyepieces 13 degree
Pupillary adjustment 55mm~78mm
Diopter adjustment ±6D
Field of view 40x (ï¿ 5.5mm), 25x (ï¿ 8.5mm),16x (ï¿ 13.5mm), 10x (ï¿ 22mm), 6x (ï¿ 34.7mm)
Slit Illumination:
Slit width Continuously variable from 0 to 14mm
at 14mm,slit becomes a circle
Slit length Continuously variable from 1mm to 14mm
Lamp 6V/20W Halogen Lamp
Slit angle 0~180 degree(continuously adjustable both vertical and horizontal)
Slit inclination 4 step 5 degree,10 degree,15 degree,20 degree
Filters Thermal safety,UV,Red-free,Cobalt Blue
Aperture diameters ï¿ 14mm,ï¿ 10mm,ï¿ 5mm,ï¿ 3mm,ï¿ 2mm,ï¿ 1mm,ï¿ 0.2mm
Base
Longitudinal movement 90mm
Lateral movement 100mm
Vertical movement 30mm
Chin-Rest
Vertical movement 80mm
Fixation Green LED

Type Galilean-Type
Magnification change Revolving Drum
Total magnification Ratio 6x,10x, 16x, 25x,40x
professional configuration
Eyepieces 12.5x
Angle between eyepieces 13 degree
Pupillary adjustment 55mm~78mm
Diopter adjustment ±6D
Field of view 40x (ï¿ 5.5mm), 25x (ï¿ 8.5mm),16x (ï¿ 13.5mm), 10x (ï¿ 22mm), 6x (ï¿ 34.7mm)
Slit Illumination:
Slit width Continuously variable from 0 to 14mm
at 14mm,slit becomes a circle
Slit length Continuously variable from 1mm to 14mm
Lamp 6V/20W Halogen Lamp
Slit angle 0~180 degree(continuously adjustable both vertical and horizontal)
Slit inclination 4 step 5 degree,10 degree,15 degree,20 degree
Filters Thermal safety,UV,Red-free,Cobalt Blue
Aperture diameters ï¿ 14mm,ï¿ 10mm,ï¿ 5mm,ï¿ 3mm,ï¿ 2mm,ï¿ 1mm,ï¿ 0.2mm
Base
Longitudinal movement 90mm
Lateral movement 100mm
Vertical movement 30mm
Chin-Rest
Vertical movement 80mm
Fixation Green LED
Power:
Input voltage 220V/110V~±10
Input frequency 50Hz/60Hz
Power consumption 30VAmax
Output voltage Lamp 6V (continuously adjustable),Fixation 3V

Microscope type Conerging Stereoscope
Magnification 2 step magnifications
Eye piece 10x
Total magnification and diameter of visual field (mm) 10X(Φ18)16X(Φ14.5)
Adjustable range of pupil distance (mm) 55-82
Adjustable diopter ±5D
Slit width(mm) 0-11adjustable
Slit height(mm) 1-10 adjustable
Slit angle 0~180°
Slit beveling Angle 0-23°
Slit inclination 5°,10°,15°,20°
Light sport Diameter (mm) Φ9,Φ8,Φ5,Φ3,Φ2,Φ1,Φ0.2
Filter heat absorption,grey,red free,cobalt blue
Illumination bulb 12V/50W halogen bulb
Voltage/frequency AC220V±10%/60HZ. AC110V±10%/50HZ±1HZ
Power 68VA
Whole packing volume 0.28m3
Numbers of carton 2
Total weight 40kg

Microscope Type : Conerging Stereoscope
Magnification: 2 steps magnifications
Eye piece: 10X
Total Magnification and DIameter of Visual Field (mm):10X(Φ18)16X(Φ14.5)
Adjustable Range of Pupil Distance (mm):55-82
Adjustable Diopter:+/-5D
Slit Width(mm):0-11adjustable
Slit Height(mm):1-10 adjustable
Slit Angle:0-180
Slit Beveling Angle :0-23
Slit Inclination :5.10.15.20
Light sport Diameter (mm):Φ9,Φ8,Φ5,Φ3,Φ2,Φ1,Φ0.2
Filter:heat absorption ,grey ,red free,cobalt blue
Illumination Bulb :12V/50W halogen bulb
Voltage/frequency :AC220V+-10%/60HZ.AC110V+-10%/50HZ+/1HZ
Power:68VA
Whole packing volume :0.28m3

Microscope magnification:
Object lens 1.3x,1.8x Object lens 1.3x,1.8x
Eye lens 10x,10x Eye lens 16x,16x
Main magnificatiaon 13x,18x Main magnificatiaon 20.8x,28.6x
Adjustment range of microscope interpupillary distance 55~82mm
Slit image regulation degree 0~10mm
Liris diaphragm diameter φ0.2,φ1,φ3,φ4,φ6,φ8,φ10mm
Color filter heat absorption,red free cobalt blue
Adjustment range of slid platform:30mm height,85mm length,80mm width
Main light source 12v 50w halogen bulb
Power source 220v 50hz
Main engine volume 330(L)*280(W)*450(H)mm
Accessories a.photographic device(add a universal camera) b.teaching device
c.option accessories

Type Galilean-Type
Magnification change Revolving Drum
Total magnification Ratio 6x,10x, 16x, 25x,40x
professional configuration
Eyepieces 12.5x
Angle between eyepieces 13 degree
Pupillary adjustment 55mm~78mm
Diopter adjustment ±6D
Field of view 40x (ï¿ 5.5mm), 25x (ï¿ 8.5mm),16x (ï¿ 13.5mm), 10x (ï¿ 22mm), 6x (ï¿ 34.7mm)
Slit Illumination:
Slit width Continuously variable from 0 to 14mm
at 14mm,slit becomes a circle
Slit length Continuously variable from 1mm to 14mm
Lamp 6V/20W Halogen Lamp
Slit angle 0~180 degree(continuously adjustable both vertical and horizontal)
Slit inclination 4 step 5 degree,10 degree,15 degree,20 degree
Filters Thermal safety,UV,Red-free,Cobalt Blue
Aperture diameters ï¿ 14mm,ï¿ 10mm,ï¿ 5mm,ï¿ 3mm,ï¿ 2mm,ï¿ 1mm,ï¿ 0.2mm
Base
Longitudinal movement 90mm
Lateral movement 100mm
Vertical movement 30mm
Chin-Rest
Vertical movement 80mm
Fixation Green LED
Power:
Input voltage 220V/110V~±10
Input frequency 50Hz/60Hz
Power consumption 30VAmax
Output voltage Lamp 6V (continuously adjustable),Fixation 3V

Image sensor 5,000,000-pixel, 1/2.5-inch high-speed and high-definition image sensor
Photo resolution 2592 × 1936
Format JPEG
Video resolution 1920 × 1080 (Full HD) 25fps/24fps
1396 × 960 (HD) 30fps
1280 × 720 (HD) 30fps
Multi-shot mode capture 10 pictures per second choose and save the clearest ones automatically
Focus mode focus by moving the mouse
Transmission interface compatible with 100M/1000M Ethernet, Standard RJ45 interface.Support multicast network.
Power Power over Ethernet, IEEE 802.3af, 48VDC
Convenient operation, find view by PC display, focus by moving the mouse Auto-exposure, auto-gain, auto-white balance
High- definition record function, the max resolution can reach 1920×1080 pixel
Equipped with auto-focus digital module and mediview image capture software
SL-390 slit lamp microscope adopts 3V3W LED module as light source which is the latest technology.
LED module has a stable performance which has low power consumption, brightens evenly and has a good color reduction and long service life (up to 20000 hours).

Specifications
Microscope: Stereoscopic
Magnification: 10X,16X
Eyepiece: 10X
Diopter adjustment:±6D
Slit Width: 0-9mm
Slit Height: 1-8mm
Slit Apertures:φ9、φ8、φ5、φ3、φ2、φ1、φ0.2(mm)
Filters: Heat Absorption, Grey, Cobait Blue, Redfree,
Slit Angle: 0°-180°
Slit Illumination:12V35W,Halogen lamp
Power source:A.C.110V or 220V,50/60Hz
Dimension & weight: 660×285×325mm,12Kg

Microscope： Base
Type: Galilean-Type Longitudinal movement:
90mm
Magnification change: Three Position revolving Drum (Standard) Lateral movement: 100mm
Five Position revolving Drum (Professional) Fine Base movement: 15mm
Eyepieces: 12.5x Vertical movement: 30mm
Angle between eyepieces: 13 degree Chin-Rest
Total magnification Ratio: 10x, 16x, 25x (Standard) Vertical movement: 80mm
6x, 10x, 16x, 25x, 40x (Professional) Fixation Target Green LED
Pupilary adjustment: 52mm~78mm Power:
Diopter adjustment: ±6D Input voltage: 220v/110v~±10ï¼…
Field of view: 25x (ï¿ 8.5mm), 16x (ï¿ 13.5mm), 10x ( Input frequency: 50Hz/60Hz
(￠22mm), 6x (￠34.7mm) Professional Power Consumption: 30VA（max）
Slit Illumination: Output voltage:
Slit width: Continuously variable from 0 to 14mm （at 14mm,slit becomes a circle ） Light: 6V
Slit length: Continuously variable from 1mm to 14mm Fixation: 3V
Aperture diameters: ï¿ 14mm,ï¿ 8mm,ï¿ 3.5mm,ï¿ 0.5mm Dimension & Weight:
Slit angle: 0-180 degree Dimension 740mm*450mm* 550mm
Filters: thermal safety,Red-free,Cobalt Blue Gross weight: 22Kg
Lamp: 6V/20W Halogen Lamp Net weight: 20Kg
